[You can read Part 1 here]
The mechanics
We have seen that electric cars are electrically complex but they are mechanically simple. The mechanics (fixed speed gearbox, differential and motor) are often in a single compact and lightweight unit with a half dozen moving parts.
There’s no clutch, no gearbox, no exhaust, no generator/alternator, no starter motor, no belts, no air filter, no oil filter, no engine oil and nothing to adjust on the motor. That only leaves the brakes and suspension. I expect there will need to be some job creation.
There is a radiator to cool the motor and an electric pump to circulate the water. This water is at a low temperature so there have to be separate means of heating the cab – a major problem with electric cars. There is also a vacuum pump for the power assisted brakes. There may well be electric fans, an electric heater and water pumps for the cab heating.
Servicing
Check fluids: motor coolant, cab heating system (water & antifreeze), brake fluid, windscreen wash. Braking system is fairly conventional and pads should last virtually the life of the car as they are so infrequently used.
Repairs
Repairs to electric cars in my experience are baffling to traditional mechanics. They will be time consuming and very expensive. There are no “pattern parts” and no “independent” repair shops as yet. The battery on my car packed in – fortunately within the guarantee period. It took six months to determine what was wrong, obtain a battery and fit it. A new battery would have been £7,000 if I’d had to pay for it. The cost of most spare parts is extortionate!
Fuel costs
The fuel is electricity, almost untaxed compared with petrol and as the car is so efficient little is used. The option exists to charge the car at home, by night, on “economy seven” electricity, or even have solar panels and charge the battery for free. (This last works only if the car is at home during the day.) Even in the worst case, costs are miniscule compared with buying petrol/diesel.
If charging is needed other than at home the costs are more complex.
The government is set to lose a lot of fuel tax. But not to worry, they have already put the idea forward that new houses should have charging points routinely fitted. This is a mere ploy, in future these can be separately metered and of course taxed.
Charging the battery
The car is ideally suited for commuting to work. It can then be charged overnight at home (possibly on cheap electricity).
The retired (such as myself) can charge it from solar PV panels for free by day if they have any. It’s surprising how many electric car owners also have solar panels!
There are two charging connections on the car. One is for DC fast charging (around 60Kw), available on motorway charging stations. The other is for slow and intermediate AC charging.
The car comes with a charging lead for slow charging at home. Most can be plugged into a 13a socket (3Kw). It’s recommended that a 13a socket is wired back to the consumer unit (fuseboard) separately for this purpose, The reason for this is that your 13a socket ring main design makes certain assumptions about electrical loads which are invalidated if an electric car is plugged in.
The other possibility is intermediate level AC charging. This is in the order of 30a (7Kw). This takes the form of a separate circuit and socket if you have one at home. At the moment the price of these is ridiculous. What should cost £30 plus labour is priced at several hundred pounds. These charing points are now becoming common in urban car parks.
Most people will be able to utilise slow charging. Remember the battery is never run to depletion, only “topped up”, something not mentioned by the sellers of such articles.
Theoretically, fast charging shortens the life of a battery due to the adverse heating effect within the battery, however the situation is complex.
Range
The problem is of course that, if you run the battery flat, it’s a tow job to some place the car can be charged
Range anxiety is much publicised. However most people use their car on a regular run and one soon becomes used to how fast the battery depletes. (There is an indicator on the dashboard.)
When you do go on a journey close to the maximum range of the car, Google Earth is your friend. It will show the exact distance .
However range is reduced by cold weather, use of the cab heater (the power comes from the traction battery), hilly terrain and driving style. Speed too is a big factor. Friction losses due to air vary as the square of speed, ie. going twice as fast, uses four times the energy, thrice as fast uses nine times the energy.
The range quoted by the manufacturers is total BS. In practice you will get around 2/3 of this. A bit like the mpg for conventional cars.
Driving
Electric cars are a wonderful drive. Once you’ve had one, you won’t want to go back to petrol/diesel. They are especially wonderful for urban driving, twisty roads and hilly roads.
They are not good on the motorway, the battery depletes at an alarming rate. No clutch or gears, seamless and ferocious acceleration from rest. Silence (apart from tyre noise) and vibration free. As you ease off the power, the regenerative braking comes in seamlessly. It’s better even than an automatic, you don’t even have to move your foot from the accelerator to the brake except at very low speeds. (less than 5mph)
The weight of the motor is insignificant, the main weight is the battery, invariably located low down under the floor of the car.
Most of us have got used to driving front engine, front wheel drive cars. Electric cars handle like a mid-engine car. This takes non-Ferrari owners some getting used to.
One snag is the regenerative braking if the car is rear wheel drive. This means the regenerative braking is rear wheel only which means you have to watch it in icy conditions, especially on bends. Electric cars are very poor in slippery conditions even with automatic traction control. Maximum motor torque comes in at zero revs.
The regenerative braking is variable, depending on the speed of the car and the state of charge of the battery. It’s almost zero if the battery is fully charged, this can catch you out in the first few hundred yards of travel.
To save the battery, in cold weather, I put a fan heater in the car for ten minutes before we set off anywhere.
Pollution
As well as being fuel efficient, electric cars take the exhaust gas pollution off the street. These gases are particularly damaging to children. Whoever heard of all these diseases, mental and physical children suffer from nowadays? They also reduce brake dust as the mechanical brakes are seldom used. Tyre dust remains a problem.
The future
If all new cars are to be electric, it’s very unlikely that everyone in the future can have one. There just won’t be enough lithium, cobalt or neodymium to go round. The lithium at least is recyclable.
Also we aren’t generating anything like enough electricity and we don’t have the infrastructure to distribute it. So enjoy your motoring while you can.
The End
~~ ** ~~ ** ~~
Links – further reading:
https://en.wikipedia.org/wiki/Mitsubishi_i-MiEV
https://en.wikipedia.org/wiki/Lithium_Triangle
https://en.wikipedia.org/wiki/Cobalt
https://en.wikipedia.org/wiki/Magnet
https://en.wikipedia.org/wiki/Synchronous_motor
https://independencedaily.co.uk/why-the-age-of-motoring-is-almost-over/
